Details
Your New Trail Boss.
A trail bike with its priorities on point: playful agility, progressive design, and killer capability – your favorite trails have never been more fun.
Where it thrives
Challenging trails, up and down hills
What it's built for
Traction, handling, durability
Highlights
- Full carbon frame / New SRAM GX Eagle 12-speed group
- RockShox Pike Select+ 140mm fork / Super Deluxe Select+ shock
- SRAM G2 RSC hydro discs / DownLow dropper post
The right stuff
29” wheels with big, grippy tires. Properly wide bars and properly short stems. Powerful brakes and dropper posts. Straightforward parts for straightforward performance.
Easy to love
Designed to be a "daily ride", the Habit is built for easy service with proven, durable suspension pivots, easy internal cable routing and no oddball proprietary stuff.
Proportional Response
Utilizing size-specific Center-of-Gravity data, the suspension is custom designed for each frame size so that every rider, from the tallest to the smallest, experiences optimized suspension performance.
The Ai Advantage
Our Ai Offset Drivetrain opens up the rear triangle for more tire clearance, while keeping the chainstays short for nimble agility. A stiffer, stronger rear wheel is just icing on the cake.
Flip Chip
A reversable chip allows riders to tweak the geometry - raise the BB and steepen the head angle of by half a degree - or to switch from 29 to 27 Plus wheels.
Downtube Protection
Have peace of mind, knowing a rugged rubber guard is protecting your piece.
LockR Pivots
Thru-axle pivot system creates a rock-solid connection between both sides of the swingarm for instantaneous response. No twist, no flex and no special tools required.
Specs
Frame | 130mm travel, BallisTec Carbon frame and swingarm, Proportional Response Tuned, Ai offset drivetrain, ISCG05, PF30, post mount brake, tapered headtube |
---|---|
Fork | RockShox Pike Select+, 140mm, DebonAir, 15 x 110mm thru-axle, tapered steered, 51mm offset |
Headset | Integrated Sealed Bearing, Tapered |
Rear Shock | RockShox Super Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound |
Rims/Wheels | WTB KOM Trail i29 TCS, 32h |
Hubs |
Front: Formula 15 x 110mm thru-axle Rear: DT Swiss, 12 x 148mm thru-axle |
Spokes | DT Swiss Competition, straight pull |
Tires |
Front: Maxxis Minion DHF, 29 x 2.5, EXO casing, tubless ready Rear: Maxxis Dissector, 29 x 2.4", EXO casing, tubeless ready |
Crankset | Truvativ Stylo 7K Eagle DUB, 30T, Ai offset |
Bottom Bracket | SRAM DUB PF30 MTB83 |
Chain | SRAM GX Eagle, 12-speed |
Rear Derailleur | SRAM GX Eagle |
Cassette/Rear Cogs | SRAM XG-1275 Eagle, 10-52, 12-speed |
Shifters | SRAM GX Eagle, 12-speed |
Handlebars | Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm |
Tape/Grips | Fabric FunGuy |
Stem | Cannondale 3, 6061 Alloy, 31.8, 0° |
Brake Levers | SRAM G2 RSC hydraulic disc |
Brakes | SRAM G2 RSC hydraulic disc, 180/180mm CenterLine rotors |
Pedals | Sold separately |
Saddle | Fabric Scoop Shallow Elite, cro-mo rails |
Seat Post | Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M-XL) |
Accessories & Extras | Custom Cannondale mud guard |
* Subject to change without notice.
